Volvo 300 series engine parts

General

Part number

Description



3100518-C

Rubber cushion for the 343, 345, and 340 with a B14 engine up to ch. 910256
(1976-Jan 1984)

Replaces Volvo reference 3100518.

3343859-C

Sump plug seal ring for the 340 with a B14, D16 or B172 engine (1976-1991).

Replaces Volvo reference 11998.
Replaces Volvo reference 3343859.

3467632

Original Volvo oil filter, M20 thread.

Replaces Volvo reference 3287999 (B14 1985 onwards).
Replaces Volvo reference 3287991 (D16 & B172).

3467632-C

Oil filter, M20 thread. Alternative supplier.

Replaces Volvo reference 3287999 (B14 1985 onwards).
Replaces Volvo reference 3287991 (D16 & B172).
Replaces Volvo reference 3467632.




3517857

Original Volvo oil filter, 3/4” thread.

Replaces Volvo reference 418432 (B14 up to 1985).
Replaces Volvo reference 1266286 (voor B19 & B200).


3100791-B

Rubber cushion suitable for the B14, B172, and D16 flywheel housing.

Replaces Volvo reference 3100791.
Replaces Volvo reference 3210653.
Replaces Volvo reference 3210484.

Expected later

Back to the top of the page
           the homepage

Fuel system

Petrol tank

B14 & B172

Part number

Description



944219-B

Rubber seal to be used in between the fuel gauge and the fuel tank of the B14 and the B172 (1984-1991).

Replaces Volvo reference 944219.
Replaces Volvo reference 3200516.
Replaces Volvo reference 3103771.
Replaces Volvo reference 3279259.
Replaces Volvo reference 3298396.

3140783-B

Rubber seal to be used in between the fuel gauge and the fuel tank of the B14 with the “old style” fuel gauge (1976-1984).

Replaces Volvo reference 3140783.

3273014-B

Petrol filler hose for the Volvo 340.
Fits all B14 and B172 models.

Replaces Volvo reference 3273014.

B19, B200 & D16

Part number

Description



944219-B

Rubber seal to be used in between the fuel gauge and the fuel tank of the B19 and the B200 (1984-1991).

Replaces Volvo reference 944219.
Replaces Volvo reference 3200516.
Replaces Volvo reference 3103771.
Replaces Volvo reference 3279259.
Replaces Volvo reference 3298396.

3413042-B

Petrol filler hose for the Volvo 340 Diesel and the 360.
Fits all B200 models after ch 216375- (1986-1991)
Fits all D16 models (1985-1991).

Replaces Volvo reference 3413042.

Back to the top of the page
           the homepage

Carburettor

Weber 32 DIR (B14)

Part number

Description



3266741-C

Pneumatic choke diaphragm for the Weber 32 DIR 83-100 (B14.1E), the 32 DIR 84-100 (B14.2S) and the 32 DIR 85-100 (B14.1S).
Used on the 343, 345, and 340 with a B14 engine and described carburrettors (1979-1981).

Replaces Volvo reference 3266741.

3267283-C

Thick insulating flange used on all 340 with a Weber carburettor.
This flange is installed between the heating flange and the inlet manifold.

Replaces Volvo reference 3267283.
Replaces Volvo reference 3277988.

3267284-C

Insulating flange gasket used on all 340 with a Weber carburettor.

Replaces Volvo reference 3267284

3267705-C

Thin insulating flange used on all 340 with a Weber carburettor.
This flange is installed between the carburettor and the heating flange.

Replaces Volvo reference 3267705.

3267705-C

3267713-C

Pneumatic choke diaphragm for the 32 DIR 48-6200 (B14.0S), the 32 DIR 57-4800 (B14.0E), the 32 DIR 74-100 (B14.0S), the Weber 32 DIR 93-100 (B14.2E), the 32 DIR 93-101 (B14.2E), the 32 DIR 95-100 (B14.3S), the 32 DIR 95-101 (B14.3S), the 32 DIR 104-100 (B14.4E), the 32 DIR 105-100 (B14.4S), the Weber 32 DIR 109-100 (B14.4E), the 32 DIR 109-101 (B14.4E) and the 32 DIR 110-100 (B14.4O).
Used on the 343, 345, and 340 with a B14 engine and described carburrettors (1976-1991).

Replaces Volvo reference 3267713.

3267727-C

Accelerator pump diaphragm for all versions of the Weber 32 DIR carburettor as used on the 343, 345 and 340 with the B14 engine (1976-1991).

Replaces Volvo reference 3267727.

3267739-C

Float chamber gasket for the Weber 32 DIR 48-6200 (B14.0S), the 32 DIR 57-4800 (B14.0E), the 32 DIR 74-100 (B14.0S), the 32 DIR 83-100 (B14.1E), the 32 DIR 84-100 (B14.2S) and the 32 DIR 85-100 (B14.1S).
Used on the 343, 345, and 340 with a B14 engine and described carburrettors (1976-1982).

Replaces Volvo reference 3267739.

3267742-C

Float for the Weber 32 DIR carburettor as used on the B14 engined 340 (1976-1991).

Replaces Volvo reference 3267742.

3267949-C

Choke control rod clip for the Weber 32 DIR carburettor.
Used on all versions of the 340 equipped with a B14 engine with a Weber 32 DIR carburettor.

Replaces Volvo reference 3267649.


3277622-C

Throttle and choke shaft bush for the Weber 32 DIR 83-100 (B14.1E), the 32 DIR 84-100 (B14.2S), the 32 DIR 85-100 (B14.1S), the Weber 32 DIR 93-100 (B14.2E), the 32 DIR 93-101 (B14.2E), the 32 DIR 95-100 (B14.3S), the 32 DIR 95-101 (B14.3S), the 32 DIR 104-100 (B14.4E), the Weber 32 DIR 109-100 (B14.4E), the 32 DIR 109-101 (B14.4E) and the 32 DIR 110-100 (B14.4O).
Used on the 343, 345, and 340 with a B14 engine and described carburrettors between 1979 en 1991.

Replaces Volvo reference 3277622.


3287035-C

Stud used to connect the airfilter housing to the Weber 32 DIR 93-100 (B14.2E), the 32 DIR 93-101 (B14.2E), de 32 DIR 95-100 (B14.3S), de 32 DIR 95-101 (B14.3S), the 32 DIR 104-100 (B14.4E), the 32 DIR 105-100 (B14.4S), the Weber 32 DIR 109-100 (B14.4E), the 32 DIR 109-101 (B14.4E) and the 32 DIR 110-100 (B14.4O)
Used on the 343, 345, and 340 with a B14 engine and described carburrettors between 1981 en 1991.

Replaces Volvo reference 3287035.

3287068-C

Float chamber gasket for the Weber 32 DIR 93-100 (B14.2E), the 32 DIR 93-101 (B14.2E), the 32 DIR 95-100 (B14.3S), the 32 DIR 95-101 (B14.3S), the 32 DIR 104-100 (B14.4E), the 32 DIR 105-100 (B14.4S), and the 32 DIR 110-100 (B14.4O).
Used on the 340 with a B14 engine and described carburrettors (1981-1991).

Replaces Volvo reference 3287068.

3287834-C

Low speed enrichment diaphragm for the 32 DIR 104-100 (B14.4E), the 32 DIR 105-100 (B14.4S), the 32 DIR 109-100 (B14.4E), the 32 DIR 109-101 (B14.4E) and the 32 DIR 110-100 (B14.4O).
Used on the 340 with a B14 engine and described carburettors (1984-1991).

Replaces Volvo reference 3287834.

3342562-C

Float chamber gasket for the Weber 32 DIR 109-100 (B14.4E) and the 32 DIR 109-101 (B14.4E).
Used on the 340 with a B14 engine and described carburrettors (1986-1991).

Replaces Volvo reference 3342562.

3342570-R

Weber 32 DIR overhaul kit.
Valid for all 32 DIR carburettors used with the B14 engined 343, 345, and 340 (1976-1991).
As this kit caters for multiple versions of the 32 DIR, some parts of this overhaul kit will remain unused after an overhaul of a carburettor.

Replaces Volvo reference 3342570.
Replaces Volvo reference 3287841.

Don’t trust your own capabilities?
Then take a look at our
overhauled Weber 32 DIR carburettors.

Solex 32 SEIA (B14.3E)

Part number

Description



3287239-R

Solex 32 SEIA overhaul kit.
Valid for all Solex 32 SEIA carburettors used with the B14.3E engined 340 (1982-1985).

Replaces Volvo reference 3287239 and parts of 3287240 and 3287241.

3287239-C

Don’t trust your own capabilities?
Then take a look at our
overhauled Solex 32 SEIA carburettors.

Solex 28-34 Cisac Z10 (B172)

Part number

Description



1270007-C

Float for the Solex 28-34 Cisac Z10 carburettor as used on the B172 engined 340
(1986 - 1989).
The brass bush must be removed from the old float and installed onto the new float before the float is fitted.

Replaces Volvo reference 1270007.

3343824-C

Insulating flange block used on all 340 with a B172 engine.
The crankcase breather pipe must be removed from the old insulating flange block and installed onto the new insulating flange block before the block is fitted.

Replaces Volvo reference 3343824

3343832-R

Solex 28-34 Cisac Z10 overhaul kit.
Valid for all Solex 28-34 Cisac Z10 used with a B172 engined 340 (1986-1989).
As this kit caters for multiple versions of the Solex 28-34 Cisac Z10, some parts of this overhaul kit will remain unused after an overhaul of a carburettor.

Replaces Volvo reference 3343832.

3344557-C

Insulating flange kit.
Contains 1 insulating flange block and 1 rubberized insulating flange gasket.
Usable for all 340 with a B172 engine.
The crankcase breather pipe must be removed from the old insulating flange block and installed onto the new nsulating flange block before the block is fitted.

Replaces Volvo reference 3344557.

Don’t trust your own capabilities?
Then take a look at our
overhauled Solex 28-34 Cisac Z10 carburettors.

Zenith-Stromberg 175 CD 2SE (B19A)

Onderdeelnr

Omschrijving



237292-C

Float for the Zenith-Stromberg 175 CD 2SE carburettor as used on the B19A engined versions of the 343, 345 and 340 between 1981 and 1984.

Replaces Volvo reference 237292.

237294-C

Float chamber gasket for the Zenith-Stromberg 175 CD 2SE carburettor as used on the B19A engined versions of the 343, 345 and 340 between 1981 and 1984.

Replaces Volvo reference 237294.

237666-C

Air valve diaphragm for the Zenith-Stromberg 175 CD 2SE carburettor as used on the B19A engined versions of the 343, 345 and 340 between 1981 and 1984.

Replaces Volvo reference 237666.

276306-R

Zenith-Stromberg 175 CD 2SE overhaul kit.
Valid for all Zenith-Stromberg carburettors used with the B19A engine on the DLS and GLS versions of the 343 and 345 (1981-1984).
To fully service your Zenith-Stromberg 175 CD 2SE we suggest that you complete this kit with the air modulator diaphragm kit 276309-C.

Replaces Volvo reference 276306.


276309-C

Air valve diaphragm for the Zenith-Stromberg 175 CD 2SE.
Valid for all Zenith-Stromberg carburettors used with the B19A engine on the DLS and GLS versions of the 343 and 345 (1981-1984). This kit contains a new return spring, diaphragm, and gaskets from the intermediate flange.

Replaces Volvo reference 276309.


276309-C

1269041-C

Carburettor-to-manifold gasket for the Zenith-Stromberg 175 CD 2SE carburettor as used on the B19A engined versions of the 343, 345 and 340 between 1981 and 1984.

Replaces Volvo reference 1269041.

1357374-C

Carburettor-to-airbox gasket for the Zenith-Stromberg 175 CD 2SE carburettor as used on the B19A engined versions of the 343, 345 and 340 between 1981 and 1984.

Replaces Volvo reference 1357374.


Don’t trust your own capabilities?
Then take a look at our
overhauled Zenith-Stromberg 175CD 2SE carburettors.

Solex 34-34 Cisac Z11 (B200)

Part number

Description



1270009-C

Needle valve for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270009.

1270009-C

1270014-C

Filter for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360
(1985 - 1989).

Replaces Volvo reference 1270014.

1270014-C

1270040-C

Accelerator pump diaphragm for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270040.

1270040-C 1

1270049-C

Float chamber gasket for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270049.

1270049-C

1270106-C

Float for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360
(1985 - 1989).
The brass bush must be removed from the old float and installed onto the new float before the float is fitted.

Replaces Volvo reference 1270106.

1270132-C

Low speed enrichment diaphragm for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270132.

1270132-C

1270133-C

Choke pull off diaphragm for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270133.

1270133-C 2

1270133-R

Choke pull off diaphragm overhaul kit for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270133.

1270133-R

1270161-C

Vent valve gasket for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

Replaces Volvo reference 1270161.

1270161-C

1326410

Original Volvo insulating flange block for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

1326410

3501510

Insulating flange gasket for the Solex 34-34 Cisac Z11 carburettor as used on the B200 engined 360 (1985 - 1989).

3501510

Don’t trust your own capabilities?
Then take a look at our
overhauled Solex 34-34 Cisac Z11 carburettors.

Back to the top of the page
           the homepage

Intake & exhaust system

Part number

Description



945654-C

Copper flashed nut M10 used on the exhaust to manifold downpipe connection.

Replaces Volvo reference 9456654.
Replaces Volvo reference 3270315.
Replaces Volvo reference 3270420.

945654-C

955894-C

Washer size M8

Replaces Volvo reference 955894.

955894-C

960148-C

Washer size M10.

Replaces Volvo reference 960148.
Replaces Volvo reference 961161.

960148-C

3100127-C

Air filter for all 343 and 345 B14 before ch. 545500 (1976-81).

Replaces Volvo reference 3100127.

3104346-C

Exhaust manifold to downpipe stud M8 used on some versions of the 343, 345 and 340 with the B14 engine.

Replaces Volvo reference 3104346.

3104346-C

3201525-C

Air filter housing gasket for the B14 engine after ch. 545500 (1981-1991)
“Made by Mac (V3M)”

Replaces Volvo reference 3201525.

3244043-C

Air filter housing gasket for the B172 engine after ch. 121000 (1986-1990)
“Made by Mac (V3M)”

Replaces Volvo reference 3244043.

3277001-C

T-piece used in the crank case ventilation on all 340 with the B14 engine (1976-1991)

Replaces Volvo reference 3277001.

3277989-C

Exhaust manifold to downpipe stud M10 used on some versions of the 300 with the B14, B19 and B200 engine.

Replaces Volvo reference 3277989.
Replaces Volvo reference 924077.
Replaces Volvo reference 978343.

3277989-C

3287936-C

Air filter for all 340 with a B14 and B172 engine after ch 545500 (1981-).

Replaces Volvo reference 3277961.
Replaces Volvo reference 3287936.

3290926-D

Decals for air filter housing 3290926 used on all 343 before ch. -332021 (1976-1977).

3290927-D

Decals for air filter housing 3290927 used on all 343, 345, and 340 with a B14 engine between ch. 332021 and 545499 (1977-1981).

3291519-C

Copper flashed nut M8 used on the exhaust to manifold downpipe connection.

Replaces Volvo reference 3291519.

3291519-C

Back to the top of the page
           the homepage

Cooling system

Part number

Description



955279-S

Installation set for the 340 B14 waterpump.
Used on all Volvo 300 series with a B14 engine after 1982.
Set exists of 5*955279-C, 1*940101-C and 6*3103863-C.

3267235-C

Thermostat B14 89°C

Replaces Volvo reference 3267235.

3293501-C

Thermostat B14 92°C

Replaces Volvo reference 3293501.

3345628-C

Thermostat B172 & D16 88°C

Replaces Volvo reference 3345628.

3345628-C

Back to the top of the page
           the homepage

Coolant hoses

B14.3E (1982-1985)

Part number

Description



3285475-B

Heater hose for the 340 B14 ch. 610000-154580 (1982-1986).

Replaces Volvo reference 3285475.

3285476-B

Heater hose for the 340 B14 ch. 610000- (MY82-).

Replaces Volvo reference 3285476.

3285477-B

Coolant hose for the 340 B14 ch. 610000-120999 (1982-1986), going from the water pump to the top of the radiator.

Replaces Volvo reference 3285477.

3287309-B

Solex carburettor coolant hose for the 340 B14 ch. 610000-120999 (1982-1986).

Replaces Volvo reference 3287309.

3287311-B

Solex carburettor coolant hose for the 340 B14 ch. 610000-120999 (1982-1986).

Replaces Volvo reference 3287311..

3298632-B

Coolant hose for the 340  B14 ch. 610000-120999 (1982-1986), going from the bottom of the radiator to the water pump.

Replaces Volvo reference 3298632.

B14.2E / B14.3S / B14.4E / B14.4S (1982-1985)

Part number

Description



3285475-B

Heater hose for the 340 B14 ch. 610000-154580 (1982-1986).

Replaces Volvo reference 3285475.

3285476-B

Heater hose for the 340 B14 ch. 610000- (MY82-).

Replaces Volvo reference 3285476..

3285477-B

Coolant hose for the 340 B14 ch. 610000-120999 (1982-1986), going from the water pump to the top of the radiator.

Replaces Volvo reference 3285477.

3287308-B

Weber carburettor coolant hose for the 340 B14 ch. 610000- (1982-).

Replaces Volvo reference 3287308.

3287310-B

Weber carburettor coolant hose for the 340 B14 ch. 610000- (1982-).

Replaces Volvo reference 3287310..

3298632-B

Coolant hose for the 340  B14 ch. 610000-120999 (1982-1986), going from the bottom of the radiator to the water pump.

Replaces Volvo reference 3298632.

B14 (1986-1991)

Part number

Description



3207962-B

Coolant hose for the 340 B14 ch. 121000- (1986-1991), going from the water pump to the top of the radiator.

Replaces Volvo reference 3207962.

3207963-B

Coolant hose for the 340  B14 ch. 121000- (1986-1991), going from the bottom of the radiator to the water pump.

Replaces Volvo reference 3207963.

3210843-B

Heater hose for the 340 B14 ch. 154580- (1986-).

Replaces Volvo reference 3210843.

3285476-B

Heater hose for the 340 B14 ch. 610000- (MY82-).

Replaces Volvo reference 3285476.

3287308-B

Weber carburettor coolant hose for the 340 B14 ch. 610000- (1982-).

Replaces Volvo reference 3287308.

3287310-B

Weber carburettor coolant hose for the 340 B14 ch. 610000- (1982-).

Replaces Volvo reference 3287310.

B172

B172  assy

Partnumber

Description



3560527-B

Coolant hose for the 340 B172  ch. 000000-765000 (1985-1989), going from the bottom of the radiator to the waterpump.

Replaces Volvo reference 35600527.


3560527-B

D16

D16  assy

Partnumber

Description



3560036-B

Coolant hose for the 340 D16 ch. 810501-120999 (1984-1986) going from the bottom of the radiator to the tube under the radiator.

Replaces Volvo reference 3560036.

This hose is only sold in combination with hose 3560037-B.


3560036-B

3560037-B

Coolant hose for the 340 D16 ch. 810501-120999 (1984-1986), going from the tube under the radiator to the waterpump.

Replaces Volvo reference 3560037.

This hose is only sold in combination with hose 3560036-B.


3560037-B

3560527-B

Coolant hose for the 340 D162  ch. 000000- (1986-1991), going from the bottom of the radiator to the waterpump.

Replaces Volvo reference 35600527.


3560527-B

B19 & B200

Part number

Description



3203164-B

Coolant hose for the 360  B200 ch. 000000- (1985-1989), going from the bottom of the radiator to the water pump.

Replaces Volvo reference 3203164.

This hose can also be used, as a replacement for Volvo reference 3293560, used for the 343, 345, and 360 B19 ch 545500-999999 (1981-1985)).

3293561-B

Coolant hose for the 343, 345, and 360 with the B19 and B200 engines ch. 545500- (1981-1989), going from the engine to the top of the radiator.

Replaces Volvo reference 3293561.

This hose can not be used on vehicles equipped with airconditioning.

Back to the top of the page
           the homepage

Ignition system

Part number

Description



272194-C

Ignition cable set for the Volvo 300 series with a B200 engine.

Replaces Volvo reference 272194.
Replaces Volvo reference 270898.
Replaces Volvo reference 271484.
Replaces Volvo reference 272196.

272194-C

1306696-C

Ignition cable set for the Volvo 300 series with a B19 engine.

Replaces Volvo reference 1306696.
Replaces Volvo reference  270478.

1306696-C

3277575-C

Dust cover out of the distributor.
Fits all 340 with a B14 engine from 1979 onwards (B14.1E/1S ==> B14.4E/4S).

Replaces Volvo reference 3277575.


3344409-C

Ignition cable set for the Volvo 340 B14 with the Renix ignition from chnr 810501-.

Replaces Volvo reference 3344409.
Replaces Volvo reference 3287924.

3344409-C

Back to the top of the page
           the homepage

© 2012-2019 Born Built Beauties

No parts of this website may be copied commercially or privately, electronically or in print
without prior written consent of Born Built Beauties.

Born Built Beauties is not affiliated in any way what so ever with the Volvo group nor with the Volvo brand.
